Entergy's large multi-line transmission substation (name not known) near US Hwy 69/96/287
located north of Highway 69, west of Rolfe Christopher Drive, south of a baseball field
February 2004

overview

overview

H-frame poles, substations behind

two receding lines of H-frame poles

two receding lines of H-frame poles

closeup of a large H-frame pole

nearby higher-voltage pole

nearby pole with 3 transformers and 2 double crossarms

pole with single crossarm
